TP-Link Archer TXE72E AXE5400 Wi-Fi 6E Bluetooth 5.3 PCIe Adapter
Experience Next-Gen Tri-Band Connectivity
The TP-Link Archer TXE72E delivers exceptional wireless performance with combined speeds up to 5400 Mbps across 6 GHz, 5 GHz, and 2.4 GHz bands. Tap into the power of Wi-Fi 6E and access the cleaner, faster 6 GHz spectrum—exclusively available on Windows 11.
Powered by Intel® Wi-Fi 6E Chipset
Built with Intel®’s latest Wi-Fi 6E technology, this adapter offers lower latency, more responsive connections, and maximizes the potential of your Wi-Fi 6E router. It ensures smooth and stable connections for gaming, streaming, and high-bandwidth tasks.
Stable Signal and Extended Range
Two multi-directional high-performance antennas enhance reception and maintain strong signal coverage, even in multi-device environments.
Bluetooth 5.3 & Enhanced Security
Enjoy faster device pairing and greater range with Bluetooth 5.3. Enhanced WPA3 security keeps your network and personal data better protected.
Built for Reliability
Gold-plated connectors and a dedicated heatsink improve stability and help maintain peak performance, even during intense workloads. The card supports full backward compatibility with previous Wi-Fi standards.
Specifications
HARDWARE FEATURES
Dimensions (W x D x H) 4.72 x 3.09 x 0.82 (inches)
120 x 78.5 x 21 (mm)
Antenna 2× High-Gain Tri-Band Antennas
WIRELESS FEATURES
Wireless Standards IEEE 802.11a/b/g/n/ac/ax
WLAN Signal Rate
6 GHz:
11ax: Up to 2402 Mbps
5 GHz:
11ax: Up to 2402 Mbps (dynamic)
11ac: Up to 1732 Mbps (dynamic)
11n: Up to 300 Mbps (dynamic)
11a: Up to 54 Mbps (dynamic)
2.4 GHz:
11ax: Up to 574 Mbps (dynamic)
11n: Up to 400 Mbps (dynamic)
11g: Up to 54 Mbps (dynamic)
11b: Up to 11 Mbps (dynamic)
WLAN Reception Sensitivity
6 GHz:
11ax HE160 MCS0: -86 dBm
11ax HE160 MCS11: -56 dBm
5 GHz:
11ax HE80 MCS0: -90 dBm
11ax HE80 MCS11: -59 dBm
11a 54 Mbps: -77 dBm
11ac VHT80 MCS0: -92 dBm
11ac VHT80 MCS9: -64 dBm
2.4 GHz:
11ax HE40 MCS0: -91 dBm
11ax HE40 MCS11: -60 dBm
11g 54 Mbps: -76 dBm
11n HT40 MCS7: -72 dBm
WLAN Transmit Power
5 GHz: 20 dBm (FCC) / 15 dBm (CE) (EIRP)
2.4 GHz: 20 dBm (FCC) / 16 dBm (CE) (EIRP)
6 GHz: 12 dBm (FCC)
WLAN Modes Infrastructure mode
Wireless Security WEP, WPA/WPA2/WPA3, WPA-PSK/WPA2-PSK
OTHERS
Certification FCC, CE, RoHS
Package Content Archer TXE72E
2× High-Gain Antennas
Low-Profile Bracket
Bluetooth Header Cable
Quick Installation Guide
Resource CD
System Requirements Supported operating systems include Windows 10, 11 (64-bit). Currently 6 GHz Band only supported on Windows 11.
Environment Operating Temperature: 0℃~40℃ (32℉~104℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Accessories Specifications Bluetooth Header Cable Length: 0.3 m
